LCD Microscope

Sold Out
Login for Price

Product Description

Get a closer look at circuit boards, coins, and stamps; enhance your view when repairing watches or jewelry, and enjoy exploring the wonders of the microscopic world clearer than ever before with the 7" HD Digital LCD Microscope.

This high performance digital magnifier is incredibly intuitive to use thanks to the large LCD viewing screen. With 12 million high definition pixels, the 1080P/720P HD display gives you a better look at all the exquisite details with exceptional clarity. ​The 75º rotatable design makes it incredibly convenient to view from the angle you prefer.

This microscope is creatively equipped with dual lenses to suit all of your needs. The 50-500X digital lens enables you to observe details of macroscopic objects like coins, printed circuit boards, insects, plants, and more. The 100-2000X microbial lens is best suited for observing cells, microorganisms, and slides.

The height adjustable 10 LED illuminator ensures your specimens are always clear and bright. Use a USB cable to connect the cell microscope and base to power the bottom light and capture pictures or video you never thought possible.

This video microscope is compatible with Windows and Mac computers so you can view high-definition video and pictures at a larger scale. Capture 4032*3024P images and 1920*1080P video and save them directly to a MicroSD card to review later, share on social media, and more.

A compact design delivers great convenience for outdoor use so you aren't limited to your lab or nearest power outlet. The long-lasting rechargeable 2600mAh battery provides 2-3 hours of use before you need to plug in. It also makes it convenient to use with a power bank for use out in the field or on-the-go.

Product Details
  • ColorsBlack
  • Materials
    ABS, Aluminum Alloy
  • Measurements
    11"L x 8.6"W x 6.2"H
  • OriginChina

— Warranty: Manufacturer's 1 Year
— HD Digital USB Microscope
— 7" IPS LCD Screen With Multiple Observation Modes
— 12 Million High Definition Pixels
— Dual Lenses For Versatile Use
— Height Adjustable 10 LED Illuminator + 1 Super Bright LED
— Built-in 2600mAh USB-Rechargeable Battery With 2- 3 Hours Of Run Time Per Charge
— Supports Connection With Mac/PC For Larger & Clearer Visual Experience
— Easily Save & Output Images & Videos
— Suitable For Microbial Observation, Observation Of Slices, Observation Of Pests & Plant Diseases, PCB Inspection, Maintenance, Precision Machinery, Printing Inspection, Welding Inspection, Textile Inspection, IC Surface Inspection, & More

— Parameters: Pixel 12 Million Pixels
— Display Screen: 7 Inch HD IPS Screen
— Magnification Time: 0-2000X
— Working Height: Approx. 0 ~ 60mm / 0 ~ 2.4inch
— Focus Method: Manual Focus
— Button Focus Range: Approx. 0 ~ 55mm / 0 ~ 2.2inch
— Image Resolution: 4032 * 3024P
— Video Resolution: 1920 * 1080P
— Light Source: 10 Light LEDs + 1 Super Bright LED (Height Adjustable)
— Image Format: JPG
— Video Format: MOV
— Power Supply: 3.7 V / 2600mAh
— Battery Life: 2-3 Hours
— Charging Time: 3.5 Hours
— Support System: Windows XP / Vista / Win7 / 8/10 / Mac OS X 10.5 & Above
— Languages: Simplified Chinese, Traditional Chinese, Japanese, English, Korean, French, Italian, German, Spanish, Russian

— Microscope
— Bracket
— Low Multiple Lens
— High Magnification Lens
— User Manual (English)
— 2 Glass Slides
— 2 Data Line
— Cleaning Cloth

Is the light source only underneath the stage or is there also a source to illuminate from above?

The light source is below the stage, so you can see the items more clearly!

Can you connect it to a larger screen?

Yes, it supports connecting to a larger screen.

At the lowest power setting can you fit an entire coin in the screen?

The visibility of a coin is determined by the focal length, you are able to see an entire coin on the screen at various power settings.

Can it see microscopic levels?

Yes, it can see microscopic levels.
